HOWO A7 336 HP 8×4 Dump Truck with A7-W Driving Cab and HW19710 transmission
Description:
HOWO A7 Dump truckS are the satisfied product with high level standard.
and the full aspect service from order to shipping.We can give customer most suitable advice when customer has special needs for your transportation or construction,the output torque automatically according to loads change.And we are specialized in this area more than 10 years,rich experience and well after-sale service.In the last,technique support and training. Customization service, as per your request, we will customize our production
Packing:
Nude Pack.The packing of the products be suitable for long distance transportation of ocean and inland.Our take measures to against moisture,shocks and rust according to the special needs of the commodity.The main machine nude, attached parts and tools put into standard export box.Within 20 days deliver the goods to main Port.Ro-Ro ship or bulk ship or according to customer requiring.
We have professional forwarding partners.
Competitive Advantage:
1. Adopt HW76 Cab single bunk,new type seat,adjustable steering wheel
2. Flexible and convenient logistic service.
3. Excellent and high-quality control
4. Adjust the output torque automatically according to loads change, and it can achieve continuously variable transmission.
5. Rich experience and well after-sale service.
6. Long lasting working life time.
7. Sufficient storage.
Description:
| Chassis Model | ZZ1317N4667A |
| Driving Type | LHD (RHD is optional) |
| Cabin | Characteristics of A7-W Luxury Driving Cab: Four-point suspension plus airbag and horizontal stabilizer; one sleeper with air conditioning; air suspension seat with armrest; encircled curtains and MP5 entertainment systems; electrically adjusted rear-view mirror with the function of heating; electrically lifted glass; manually and electrically raised driving cab. |
| Engine | Make: SINOTRUK Diesel 4-stroke direct injection diesel engine Engine model: WD615.69 , Euro 2, 336 HP 6-cylinder in-line with water cooling, turbo-charging and intercooling Displacement: 9.726 L |
| Transmission | HW19710, 10F & 2R Ratio: 14.28, 10.62, 7.87, 5.88, 4.38, 3.27, 2.43, 1.80, 1.34, 1.00, 13.91(R1), 3.18(R2) |
| Steering | ZF8118, hydraulic steering with power assistance |
| Front Axle | HF9, 2x9000 KGS |
| Rear Axle | HC16, 2x16000 KGS Ratio:5.73 |
| Propeller Shaft | Double universal joint propeller shaft with gear-shaped coupling flange |
| Chassis | Frame: U-profile parallel ladder frame with section of 300x80x8mm, and reinforced subframe all cold riveted cross members Front suspension:10 semi-elliptic leaf spring, hydraulic telescopic double-action shock absorbers and stabilizer Rear suspension:12 leaf semi-elliptic springs, bogie spring and stabilizer |
| Brake | Service brake: dual circuit compressed air brake Parking brake (emergency brake): spring energy, compressed air operating on front shaft and rear wheels Auxiliary brake: engine exhaust brake |
| Electrics | Operating voltage: 24 V, negative grounded Starter: 24 V, 5.4 Kw Alternator: 3-phase, 28 V, 1500 W Batteries: 2 x 12 V, 165 Ah Cigar-lighter, horn, headlamps, fog lights, brake lights, indicators and reverse light |
| Tyres | 12.00R20, radial tyres with one spare tyre |
| Fuel Tank | 400L |
| Cargo Body | 8000x2300x1600mm with front lifting system,30CBM |
| Overall Dimension | 10000x2550x3400 mm |
