Brand New 6X4 HOWO Flatbed Truck Mounted Crane Telescopic Boom Truck

Brand New 6X4 HOWO Flatbed Truck Mounted Crane Telescopic Boom Truck

Product Description
Our Truck Crane—also called a hydraulic truck crane, mobile crane, truck‐mounted crane, or lorry crane—is a versatile lifting solution engineered for demanding industrial and commercial jobs. Whether you call it a truck with loading crane or a truck cargo crane, it delivers reliable performance in tight spaces and harsh outdoor environments.

Key Features

• Lifting Capacity
  Ranges from 2 t to 200 t to cover everything from light‐duty tasks to the heaviest loads.

• Arm Configurations

  • Straight Boom: Exceptional stability for standard lifts.

  • Folding Boom: Added reach and flexibility for complex jobs in confined areas.

• Remote Control Option
  Enables safe, precise operation from up to 50 m away.

• Chassis Compatibility
  Easily mounts on major brands—Dongfeng, FAW, Foton, Sinotruk, Shaanxi (Shacman), T-King, Dayun, Yuejin, JMC, JAC, and more.

• Premium Hydraulic System
  High-flow pumps, reinforced hoses, and precision valves ensure smooth, dependable lifting under continuous use.

• Customizable Layouts
  Choose boom type, lifting capacity, outriggers, and chassis to suit your exact needs.

Applications

• Construction: Transport and place steel beams, concrete forms, and materials.

• Warehousing & Logistics: Load/unload pallets, crates, and bulky cargo in tight aisles.

• Ports & Terminals: Handle containers, engines, and bulk goods with ease.

• Salvage & Recovery: Rescue vehicles and lift heavy debris in challenging terrains.

• Mining & Manufacturing: Install machinery, move heavy components, and support assembly lines.

Why Choose Our Truck Crane?

• Factory-Direct Pricing: Competitive rates without middle-man markups.

• Superior Build Quality: Durable steel structures and top-grade components for long life.

• Full After-Sales Support: On-site training, preventive maintenance, and genuine spare parts.

• Tailored Solutions: Configure specifications to match your budget and workflow.

  Name	HOWO CARGO TRUCK WITH CRANE
  Drive type	6×4
  Kerb mass (kg)	12500
  Rated loading capacity(kg)	---
  Total mass(kg)	25000
  Max. speed (km/h)	75
  Min. turning circle (m)	18
  Approach/Departure(°)	16/70
  Max. gradeability (%)	60
  Appearance dimensions (mm)	12000×2500×3450
  Wheel base (mm)	4600+1350
  Overhang(front/rear)	1500/725
  Track width (mm) (front/rear)	2022/2041
  Engine	CNHTC Engine,1WD615.47,371hp E-II
  Rated output power	309kw
  Torque(N.m r. p. m)	1820/1100-1500
  Displacement(L)	9.726
  Fuel tank capacity (L)	400L
  Tyre:	315/80R22.5 10+1pc
  Clutch	φ430 diaphragm spring
  Gearbox	Transmission	HW19710, 10 forward&2 reverse Manual
  Front axle	HF9
  Drive axle	HC16 ratio 4.8
  Steering	ZF8118 (left-hand drive)
  Brake	Service brake	With dual-circuit compressed air brake
  	Park brake	Power spring brake acting on front & rear wheel
  	Auxiliary brake	Engine exhaust valve brake
  Cab	HW76 Cab with Single sleeper A/C
  	With Wind scooper and air guide sleeve
  Battery	165AH
  Cargo Carriage Internal Dimensions	7200x2400x600(LxWxH)mm
  Steel thickness of Carriage:	Floor: 3mm, Side:1.5mm
  Crane	12tons straight arm crane
  Delivery date	40 working days after receiving the down payment.
