Sinotruck HOWO 25t-100t 8*4 Diesel Used Transport Delivery Lorry 12 Wheels Truck

Brand Name : sinotruk

Model Number : howo

Certification : iso/ccc

Place of Origin : China

MOQ : 1 unit

Price : Negotiation

Payment Terms : L/C,T/T

Supply Ability : 500 units/month

Delivery Time : 30-45 work days

Packaging Details : Nude

product name : howo 8*4 dump truck

Load Capacity : 51-60t

Emission Standard : Euro 2

Drive Wheel : 8×4

Engine Capacity : ＞8L

Seats : ≤5

Horsepower : 351-450hp

Tire Design : Radial

Dumping Type : Front Lifting Style

Gear : 12 Gears

Contact Now

Sinotruck HOWO 25t-100t 8*4 Diesel Used Transport Delivery Lorry 12 Wheels Truck

HOWO 8x4 Dump Truck: A Reliable Choice for Heavy-Duty Transport

The HOWO 8x4 dump truck is a robust and versatile heavy-duty vehicle designed to meet the demands of construction, mining, and logistics operations. Here’s a detailed overview of its features and specifications:

Key Specifications

  • Chassis Model: ZZ3317N3567C1
  • Driving Type: 8x4
  • Production Year: 2024 (new model)
  • Engine:
    • Make: SINOTRUK
    • Model: WD615.47, Euro 2, 371 HP / WP12.400E201, Euro 2, 400 HP
    • Type: 6-cylinder in-line, water-cooled, turbocharged and intercooled
    • Displacement: 9.726 L
  • Transmission: HW19710, 10F & 2R, with PTO
  • Steering: ZF power steering, model ZF8118, hydraulic steering with power assistance
  • Front Axle: HF9, 2×9000 KGS, double T-cross section beam
  • Rear Axle: HC16, 2×16000 KGS, pressed axle housing, central single reduction with hub reduction and differential locks
  • Ratio: 5.73
  • Propeller Shaft: Double universal joint propeller shaft with gear-shaped coupling flange
  • Chassis:
    • Frame: U-profile parallel ladder frame with section of 300x80x8mm, reinforced sub-frame with cold-riveted cross members
    • Front Suspension: 10 semi-elliptic leaf springs, hydraulic telescopic double-action shock absorbers, and stabilizer
    • Rear Suspension: 12 leaf semi-elliptic springs, bogie spring, and stabilizer
  • Brake System:
    • Service Brake: Dual circuit compressed air brake
    • Parking Brake (Emergency Brake): Spring energy, compressed air operating on front shaft and rear wheels
    • Auxiliary Brake: Engine exhaust brake
  • Electrics:
    • Operating Voltage: 24 V, negative grounded
    • Starter: 24 V, 5.4 Kw
    • Alternator: 3-phase, 28 V, 1500 W
    • Batteries: 2×12 V, 165 Ah
    • Additional Features: Cigar lighter, horn, headlamps, fog lights, brake lights, indicators, and reverse light
  • Tires: 12.00R20, radial tires with one spare tire (optional: 315/80R22.5 tubeless tires)
  • Fuel Tank: 300 L
  • Cargo Body:
    • Dimensions: 7300×2300×1700 mm, 28.54 CBM
    • Floor Thickness: 8 mm, Side Thickness: 6 mm
    • Front Lifting System: Available

Features and Advantages

  • Robust Design: Built with a strong and reliable chassis, ensuring durability in demanding environments.
  • High Capacity: Large cargo body capacity makes it ideal for large-scale transport tasks.
  • Ergonomic Cab: Features a comfortable HW76 cab with a built-in sleeper, air conditioning, and advanced controls for operator comfort.
  • Advanced Safety: Integrated braking system and complete electrical configuration ensure driving safety and stability.
  • Versatility: Adaptable to various engineering needs, making it popular in construction and mining industries.

Applications

The HOWO 8x4 dump truck is widely used in:
  • Construction: Transporting materials like sand, gravel, and debris.
  • Mining: Hauling ores and heavy loads.
  • Logistics: Efficient transportation for large-scale projects.
Traction 8X4
Driving type LHD (RHD is option)
Cabin HW NX Cab, with one sleeper bed, two seats, with A/C
Type Forward control cab, hydraulically tiltable by 60°
Construction Current standard all steel construction
Instrument panel Clearly visible,ndicators of compressed air pressure, coolant temperature,engine oil pressure and battery charging
Seats 4-point support fully floating suspension + shaock absorbers driver sdjustabable & passenger fixed
Seat safe belts For driver & passenger
Engine Brand SINOTRUK
Model WD615.47 371hp
Emission Euro II
Engine type Diesel 4-stroke direct injection engine, 6-cylinder in line with water cooling ,turbo-charging
Displacement 9.726 L /Diesel


Compression ratio 17:1
Bore/Stroke(mm) 126/130
Specific fuel consumption 198g/Kwh
Gear Model HW19710
Brand SINOTRUCK
Type 10 Forward& 2 Reverse
Clutch: Φ430 Diaphragm type, Single dry frictional disc, Hydraulic boosting hydraulically operating with air assistance
Steering Model ZF8098
Tyre 12.00R20 Tyres
Fuel tank 300L Iron Tank with locking fuel cap, fitted to the off side of the chassis
Front axle: HF9 tons front axle with drum brake
Rear axle HC16 16tons
